| Printing |
Line Drawings |
26 sec/page on A1/D, 116 A1/D
prints per hour |
|
Print resolution |
Up to 2400 x 1200 dpi |
|
Technology |
HP Thermal Inkjet |
|
Margins |
Roll: 0.1 x 0.1 x 0.1 x 0.1 in
(3 x 3 x 3 x 3 mm) |
|
|
Sheet: 0.1 x 0.67 x 0.1 x 0.1 in
(3 x 17 x 3 x 3 mm) |
|
Ink types |
Dye-based (C, G, M, pK, Y);
pigment-based (mK) |
|
Ink cartridges |
6 (C, M, Y, G, pK, mK) |
|
Printheads |
3 universal printheads, 2 colors
each: mK-Y / C-M / G-pK |
|
|
|
| Media |
Handling |
Sheet feed, roll feed, automatic
cutter |
|
Sheet Size |
8.3 x 11 to 44 x 66 in (210 x
279 to 1118 x 1676 mm) |
|
Roll size |
11 to 44 in (279 to 1118 mm) |
|
Thickness |
Up to 31.5 mil (0.8 mm) |
|
|
|
| Applications |
|
Line drawings, Renderings,
Presentations, Maps, Orthophotos |
|
|
|
| Memory |
|
128 GB virtual9 500 GB Self
Encrypted hard disk (AES-256 Encrypted) |
|
|
|
| Connectivity |
Interfaces (standard) |
Ethernet, Fast Ethernet, Gigabit
Ethernet, 10/100/1000Base-T Ethernet (802.3, 802.3u, 802.3ab); USB Type-A
host port |
|
Print languages (standard) |
Basic Printer: HP-GL/2, TIFF,
JPEG, URF, CALS G4 PostScript Printer: Adobe PostScript 3, Adobe PDF 1.7 ext
3, HP-GL/2, TIFF, JPEG, URF, CALS G4 |
|
Printing Paths |
HP driver for Windows and MAC OS
X, direct printing from USB flash drive, email printing, HP Smart app, HP
Click printing software, HP Print Service for Android, Apple AirPrint driver |
|
Drivers |
Basic Printer: Raster drivers
for Windows and macOS PostScript Printer: Raster drivers for Windows and
macOS; PostScript and PDF Windows drivers and macOS PostScript driver |
|
|
|
| Security
Features |
|
HP Secure Boot, Whitelisting10,
Secure-IPP, IPsec/Firewall, Certificates management, 802.1X, TLS 1.0/1.1/1.2,
HP Web Jetadmin compatible, HP JetAdvantage Security Manager compatible,
self-encrypting HDD, PIN printing |
|
|
|
| Dimensions
(w x d x h) |
Printer |
70.9 x 27.4 x 39.3 in (1802 x
695 x 998 mm) |
|
Shipping |
77 x 30.3 x 28 in (1955 x 770 x
710 mm) |
|
|
|
| Weight |
Printer |
Single-roll printer: 159 lb (72
kg), Double-roll printer: 163 lb (74 kg) |
|
Shipping |
Single-roll printer: 278 lb (126
kg), Double-roll printer: 282 lb (128 kg) |
|
|
|
| What’s in
the box |
|
HP DesignJet T1700 Printer,
printheads, Introductory ink cartridges, printer stand, spindle, setup
poster, introductory information, warranty, power cords, label kits |
|
|
|
| Software |
|
HP Click, HP Utility for Mac and
Windows, HP WebJet Admin, HP Embedded Web Server, HP JetAdvantage Security
Manager, HP Partner Link, HP MPS |
|
|
|
| Environmental
ranges |
Operating temperature |
Operating temperature: 41 to
104°F (5 to 40°C) |
|
Operating humidity |
20 to 80% RH (non-condensing) |
|
|
|
| Acoustic |
Sound pressure |
45 dB(A) (printing); 32 dB(A)
(ready); < 15 dB(A) (sleep) |
|
Sound power |
6.1 B(A) (printing); 5.0 B(A)
(ready); < 3.1 B(A) (sleep) |
|
|
|
| Power |
Consumption |
< 100 W (printing); < 24 W
(ready); < 0.3 W (< 6.5 W with embedded Digital Front End) (sleep); 0.1
W (offf) |
|
Requirements |
Input voltage (auto ranging)
100-240 V (± 10%), 50/60 Hz (± 3 Hz), 2 A max |
|
|
|
| Certification |
Safety |
USA and Canada (CSA certified);
EU (LVD and EN 60950-1 compliant); Russia, Belarus, Khazakstan (EAC);
Singapore (PSB); China (CCC); Argentina (IRAM); India (BIS) |
|
Electromagnetic |
Compliant with Class B
requirements, including: USA (FCC rules), Canada (ICES), EU (EMC Directive),
Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI), Korea (KCC),
South Africa (SABS) |
|
Environmental |
ENERGY STAR; WEEE; RoHS (EU,
China, Korea, India); REACH; EPEAT Silver |
|
|
|
| Warranty |
|
One-year limited hardware
warranty |
