Save space by placing the world's smallest plotters wherever they fit best, using the built-in stand.
Save time by connecting and printing right away with Wi-Fi capabilities.
Save money by printing in-house with HP’s most affordable plotters.
RADICALLY SIMPLE—From setup to printout
Speed up your PDF printing process with free HP Click software.
Easily access your files from cloud folders and print them using your smartphone with the HP Smart app.
Impress your clients with beautifully designed posters using the free and intuitive HP Poster Web app.
DESIGNJET QUALITY— From the most trusted brand
Meet client expectations with high-quality, highspeed A1/D-size printing, as fast as 27 seconds.
Get perfectly matched colour on both smalland large-format prints thanks to the built-in A3/A4 tray.
Achieve precise details with up to 2400 dpi and original HP/GL-2 capability.
Convey your ideas with bold images, sharp lines on plain paper for any application with HP Bright Office Inks.
Technical Specifications
Print Print speed T530 24-in: 30 sec/page on A1, 76 A1 prints per hour Print resolution Up to 2400 x 1200 optimised dpi Technology HP Thermal Inkjet Margins Roll: 5 x 5 x 5 x 5 mm Sheet: 5 x 5 x 5 x 5 mm Ink types Dye-based (C, M, Y); pigment-based (K) Ink drop 5.5 pl (C, M, Y); 12 pl (K) Printheads 1 (cyan, magenta, yellow, black) Printhead nozzles 1376 Line accuracy ±0.1% Minimum line width 0.02 mm (HP-GL/2 addressable) Max optical density 8 L* min/2.10 D
Media Handling Sheet feed, roll feed, input tray, automatic horizontal cutter Sheet size 24-in: Input tray: 210 x 279 to 330 x 482 mm manual feed: 330 x 482 to 610 x 1897 mm Roll size 24-in: 279 to 610 mm Standard sheets 24-in: Input tray: A4, A3 manual feed: A2, A1 Grammage 60 to 280 g/m² (roll/manual feed); 60 to 220 g/m² (input tray) Thickness Up to 0.3 mm (Up to 11.8 mil)
Applications Line drawings; Presentations; Renderings
Memory 1 GB Hard disk None
Connectivity Interfaces Fast Ethernet (100Base-T), Hi-Speed USB 2.0, Wi-Fi Print languages (standard) HP -GL/2, HP-RTL, JPEG, CALS G4 Printing paths Windows printer drivers, HP Print Service Plugin for Android, HP Print for Chrome for Chrome OS Drivers Raster driver for Windows
Dimensions (w x d x h) Printer 987 x 530 x 932 mm Shipping 1090 x 570 x 480 mm Printer 26 kg Shipping 48.5 kg
What's in the box HP DesignJet T525 24-in Printer, printer stand, printhead, introductory ink cartridges, spindle, quick reference duise, setup poster, power cord.
HP Software and solutions HP Click, HP DesignJet Utility for Windows, HP Smart app, HP Poster Web app
Environmental Ranges Operating temperature 5 to 40ºC (41 to 104ºF) Operating humidity 20 to 80% RH Storage temperature -25 to 55ºC (-13 to 131ºF)
Power Consumption < 35 W (printing), < 6 W (ready), < 4.5 W (sleep), < 0.3 W (standby) Requirements Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz (±3 Hz), 1200 mA max
Certification Safety USA and Canada (CSA certified); EU (LVD and EN 60950-1 compliant); Russia, Belarus, Khazakstan (EAC); Singapore (PSB); China (CCC); Argentina (IRAM); India (BIS); Mexico (NYCE) Electromagnetic Compliant with Class B requirements, including: USA (FCC rules), Canada (ICES), EU (EMC/R&TTE Directives), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI); Certified as Class A product: Korea (KCC) Environmental ENERGY STAR; WEEE; EU RoHS; REACH; EuP; EPEAT
