| Printing |
Printing modes |
50 m²/hr (538 ft²/hr) -
Billboard (2 pass |
|
|
23 m²/hr (248 ft²/hr) - Outdoor
High Speed (4 pass) |
|
|
17 m²/hr (183 ft²/hr) - Outdoor
Plus (6 pass) |
|
|
13 m²/hr (140 ft²/hr) - Indoor
Quality (8 pass) |
|
|
10 m²/hr (108 ft²/hr) - Indoor
High Quality (10 pass) |
|
|
6 m²/hr (65 ft²/hr) - Backlits,
Textiles, and Canvas (16 pass) |
|
|
5 m²/hr (54 ft²/hr) - High
Saturation Textiles (20 pass) |
|
Print resolution |
Up to 1200 x 1200 dpi |
|
Margins |
5 x 5 x 5 x 5 mm (0.2 x 0.2 x
0.2 x 0.2 in) |
|
Ink types |
HP Latex Inks |
|
Ink cartridges |
Black, cyan, light cyan, light
magenta, magenta, yellow, HP Latex Optimizer |
|
Cartridge size |
775 ml |
|
Printheads |
6 (2 cyan/black, 2
magenta/yellow, 1 light cyan/light magenta, 1 HP Latex Optimizer) |
|
Color consistency |
Average ≤ 1 dE2000, 95% of
colors ≤ 2 dE2000 |
|
|
|
| Media |
Handling |
Roll feed; take-up reel
(optional); automatic cutter (for vinyl, paper-based media, backlit polyester
film) |
|
Media types |
Banners, self-adhesive vinyls,
films, papers, wallcoverings, canvas, synthetics, (fabrics, mesh, textiles,
and any other porous materials that require a liner) |
|
Roll size |
254 to 1371-mm (10 to 54-in)
rolls; 580 to 1371-mm (23 to 54-in)
rolls with full support |
|
Roll weight |
42 kg (92.6 lb) |
|
Roll diameter |
250 mm (9.8 in) |
|
Thickness |
Up to 0.5 mm (19.7 mil) |
|
|
|
| Applications |
|
Banners, Displays, Exhibition
and event graphics, Exterior signage, Indoor posters, Interior decoration,
Light boxes – film, Light boxes – paper, Murals, POP/POS, Posters, Vehicle
graphics |
|
|
|
| Connectivity |
Interfaces (standard) |
Gigabit Ethernet (1000Base-T) |
|
|
|
| Dimensions
(w x d x h) |
Printer |
2561 x 840 x 1380 mm (101 x 33 x
54 in) |
|
Shipping |
2795 x 760 x 1250 mm (110.1 x 30
x 49.3 in) |
|
|
|
| Weight |
Printer |
208 kg (459 lb) |
|
Shipping |
290 kg (639.5 lb) |
|
|
|
| What’s in
the box |
|
HP Latex 335 Printer;
printheads; maintenance cartridge; printer stand; spindle; user maintenance
kit; edge holders; quick reference guide; setup poster; documentation
software; FlexiPrint BASIC HP Edition RIP; power cords |
|
|
|
| Environmental
ranges |
Operating temperature |
15 to 30 C (59 to 86 F) |
|
Operating humidity |
20 to 80% RH (non-condensing) |
|
Storage temperature |
-25 to 55°C (-13 to 131°F) |
|
|
|
| Acoustic |
Sound pressure |
55 dB(A) (printing); 39 dB(A)
(ready); < 15 dB(A) (sleep) |
|
Sound power |
7.4 B(A) (printing); 5.7 B(A)
(ready); < 3.5 B(A) (sleep) |
|
|
|
| Power |
Consumption |
2.6 kW (printing); 72 watts
(ready); < 2.5 watts (sleep) |
|
Requirements |
Input voltage (auto ranging)
200-240 V (±10%) two wires and PE; 50/60 Hz (±3 Hz); two power cords; 3 A max
for printer and 13 A max per curing |
|
|
|
| Certification |
Safety |
IEC 60950-1+A1+A2 compliant; USA
and Canada (CSA listed); EU (LVD and EN 60950-1 compliant); Russia, Belarus,
and Kazakhstan (EAC); Argentina (IRAM); China (CCC); India (BIS) |
|
Electromagnetic |
Compliant with Class A
requirements, including: USA (FCC rules), Canada (ICES), EU (EMC Directive),
Australia and New Zealand (RCM), China (CCC), Japan (VCCI), Korea (KCC),
Russia, Belarus, and Kazakhstan (EAC) |
|
Environmental |
ENERGY STAR; WEEE; RoHS (EU,
China, Korea, India, Ukraine, Turkey); REACH; EPEAT Bronze; OSHA; CE marking
compliant |
|
|
|
| Warranty |
|
1 year, provided that the End of
Installation Registration is completed by a HP authorized reseller or by the
user, in case of customer installations. In this case, the online training
must be completed by the customer and the printer must be connected to the
Customer Involvement Program or Printer Data Sharing program, enabling the
option of sending the printer’s serial number if possible |
